OPERATING SYSTEM
Windows 10 Pro 64-bit
PROCESSOR
Intel® i5 - 7300U 2.60 GHZ 3MB 2133 2C6 processor
CHIPSET
Multi-chip package
ENVIRONMENTAL
Low halogen
MEMORY
4 GB DDR4-2400 SDRAM (1 x 4 GB)
STANDARD MEMORY NOTE
Transfer rates up to 2400 MT/s.
MEMORY SLOTS
2 SODIMM
INTERNAL DRIVE BAYS
One M.2
INTERNAL STORAGE
128 GB SATA SSD or 256 GB SATA SSD
GRAPHICS (INTEGRATED)
Intel® HD Graphics 610
I/O PORT LOCATION
Back
PORTS
1 cash drawer connector; 1 power connector; 1 RJ-45; 1 USB Type-C™ (charging); 2 serial; 4 USB 3.0; 1 Powered 24 Volt USB; 2 Powered 12 Volt USB
EXTERNAL I/O PORTS FOOTNOTE NUMBER
[13]
I/O PORT LOCATION
Side
PORTS
1 headset connector
EXTERNAL I/O PORTS FOOTNOTE NUMBER
[14]
EXPANSION SLOTS
1 M.2
AUDIO
Integrated HD audio with Realtek ALC3228 codec with standards internal speakers and stereo headphone jack
MAGNETIC STRIPE READER
HP Retail Integrated Dual-Head MSR; Optional integrated magnetic stripe reader; Single-head, bi-directional, and encryption capable
NETWORK INTERFACE
Realtek RTL8153 LAN
POWER
120 W, 88% efficiency, active PFC (basic base)
OPERATING HUMIDITY RANGE
20 to 85% RH
MINIMUM DIMENSIONS (W X D X H)
33.62 X 21.64 X 1.76 cm (head unit); 9.6 x 9.6 x 26 cm (stand with column printer); 28.4 x 16.2 x 2.92 cm (connectivity base)
WEIGHT
1.33 kg (rotate stand); 1.09 kg (fixed stand); 1.38 kg (head unit); 0.56 kg (connectivity base); 1.94 kg (printer)
SECURITY MANAGEMENT
Credential guard and password protection; Device guard; HP BIOSphere with SureStart Gen 3; HP FingerPrint Sensor; Power-on password (via BIOS); Setup password (via BIOS); Trusted Platform Module TPM 2.0 Embedded Security Chip; USB enable/disable (via BIOS); VESA mounting
